Capacity & Model
|
6 Lit. “WHB-6”
|
11 Lit. “WHB-11”
|
22 Lit. “WHB-22”
|
- Range & Accuracy
|
Ambient + 5 ℃ to 250 ℃, ±1.5℃
|
|
Temp. Uniformity & Probe
|
±3.0℃, PT100
|
|
Heating Power
|
1.5 kW
|
2.0 kW
|
2.5 kW
|
|
Timer & Alarm
|
99hr 59min (Delay & Continuous run), Error status & Timer-end
|
|
Display
|
Digital LCD with Back- Light Function
|
|
Controller
|
Digital Fuzzy Controller with Jog-Shuttle Switch (Turn+Push)
|
|
Safety Circuit
|
Over-Temp./-Current protection, Sensor Error Detection
|
|
Material
|
Stainless steel (＃304)-Internal, Powder Coated steel-External, 50 mm Thickness Ceramic Fiber-Insulation
|
|
Lid
|
Stainless steel Flat Lid Included
|
|
Drain Valve
|
Mounted
|
|
Dimension (w×d×h)
|
Effective Space
|
270×180×h110 mm
|
300×250×h110 mm
|
400×300×h140 mm
|
|
Internal
|
270×180×h150 mm
|
300×250×h150 mm
|
400×300×h180 mm
|
|
External
|
425×305×h340 mm
|
425×375×h340 mm
|
525×425×h370 mm
|
|
Packing Size (mm) &
Gross Weight
|
470×400×h500 mm,
23 kg
|
600×490×h500 mm,
25 kg
|
600×490×h500 mm,
39 kg
|
|
Power Supply & Cord/Plug�
|
1 Phase, AC 120 V, 60 Hz or 230 V, 50 / 60 Hz
|
