Model
|
Available 5×Viscometer, 30Lit. “WVB- 30”
|
|
Temp. Range & Accuracy
|
Ambient +5℃ to 100 ℃, ±0.1℃
|
|
Temp. Resolution
|
0.1℃-Display, 0.1℃-Control
|
|
Temp. Uniformity & Probe
|
±0.2℃ , PT100
|
|
Heating Power
|
2 kW
|
|
Pump
|
Magnetic Drive, Max. Flow 30 Lit./min
|
|
Timer & Alarm
|
99hr 59min (Delay & Continuous run), Error status & Timer-end
|
|
Display
|
Digital LCD with Back- Light Function
|
|
Controller
|
Digital Fuzzy Controller with Jog-Shuttle Switch (Turn+Push)
|
|
Safety Circuit
|
Over-Temp./-Current protection, Sensor Error Detection
|
|
Lid
|
Included 5- or 9-Holes Stainless steel Lid for Viscometer Holder
|
|
Drain Valve
|
Mounted
|
|
Viewing Window Size(mm)
|
230×180
|
|
Material
|
Stainless steel (＃304)-Internal, Powder Coated steel-External, Vacuum Sealed and Tempered Safety Pair Glasses-Window
|
|
Dimension (w×d×h)
|
Effective Space (mm)
|
330×300×h260 mm
|
|
Internal (mm)
|
350×300×h300 mm
|
|
External (mm)
|
585×375×h420 mm
|
|
Packing Size (mm) & Gross Weight (kg)
|
640×450×h500 mm,
24 kg
|
|
Power Supply & Cord/Plug�
|
1 Phase, AC 120V, 60Hz or 230V, 50 / 60Hz
|
