Temp. Range & Model
|
Down to -40℃
“WCT- 40”
|
Down to -80℃
“WCT- 80”
|
|
Capacity
|
10 Lit.
|
|
Cold Trap Type
|
2×Glass Trap
|
|
Refrigerator
|
1/2 HP
|
1 HP
|
|
Power Consumption
|
900 W
|
1.8 kW
|
|
Refrigerant
|
R-404A
|
HFC
|
|
Display
|
Digital LCD with Back- Light Function
|
|
Controller
|
PID Controller with Jog-Shuttle Switch (Turn+Push)
|
|
Drain Valve
|
Mounted
|
|
Safety Circuit
|
Over Current protection, Sensor Error Detection, Leakage Breaker
|
|
Material (w×d×h)
|
Stainless steel (＃304)-Internal,
Powder Coated steel, 1.2t, Doublepaint & Baked-External, 20 mm Thickness Polyurethane-Insulation
|
|
Dimension (mm)
|
220×220×h210 mm-Internal, 377×453×h705 mm-External
|
|
Packing Dimension (mm) and Gross Weight (kg)
|
560×500×h1,010,
67 kg
|
680×640×h1,130,
90 kg
|
|
Power Supply & Cord/Plug�
|
1 Phase, AC 120 V, 60 Hz or AC 230 V, 50 / 60 Hz
|
