- of Extraction Holes & Model
|
4 Places
“WEB - 4”
|
6 Places
“WEB - 6”
|
8(4×2) Places
“WEB - 8”
|
- Range & Accuracy
|
Ambient +5 ℃ to 100 ℃, ±0.2℃
|
- Uniformity & Sensor
|
±1.0℃, PT100
|
|
Heating Power
|
1.4 kW
|
1.8 kW
|
1.4 kW×2
|
|
Timer & Alarm
|
99hr 59min (Delay & Continuous run), Error status & Timer-end
|
|
Display
|
Digital LCD with Back - Light Function
|
|
Controller
|
Digital Fuzzy Controller with Jog-Shuttle Switch (Turn+Push)
|
|
Safety Circuit
|
Over-Temp./-Current protection, Sensor Error Detection, Leakage Breaker
|
|
Material
|
Stainless steel (＃304)-Internal, Powder Coated steel-External, Stainless steel-Holding Frame
|
|
Lid & Top Opening Dia.
|
Concentric Ring Cover Sets included, Φ110 mm
|
|
Drain Valve
|
Mounted
|
|
Dimension (w×d×h)
|
Internal
|
610×160×h160 mm
|
910×140×h160 mm
|
610×290×h160 mm
|
|
External
|
720×245×h275 mm
|
975×245×h275 mm
|
720×375×h275 mm
|
|
Packing Size (mm) and Gross Weight (kg)
|
710×310×h300,
18 kg
|
1,030×320×h370,
25 kg
|
880×420×h300,
34 kg
|
|
Power Supply�
|
1 Phase, AC 120 V / 60 Hz or 230 V, 50 / 60 Hz
|
