Capacity & Models
|
6 Lit.
“WB - 6”
|
11 Lit.
“WB - 11”
|
22 Lit.
“WB - 22”
|
- Range & Accuracy
|
Ambient＋5℃~ 100℃, ±0.1℃
|
|
Temp. Resolution
|
0.1℃-Display, 0.1℃-Control
|
- Uniformity & Probe
|
±1.0℃, PT100
|
|
Heating Power
|
800 W
|
1 kW
|
2 kW
|
|
Timer & Alarm
|
99hr 59min (Delay & Continuous run), Error status & Timer-end
|
|
Display
|
Digital LCD with Back- Light Function
|
|
Controller
|
Digital Fuzzy Controller with Jog - Shuttle Switch (Turn＋Push)
|
|
Safety Circuit
|
Over-Temp. / -Current protection, Sensor Error Detection
|
|
Material
|
Stainless steel (＃304)-Internal, Powder Coated steel-External
|
|
Lid
|
included Stainless steel Flat Lid, Optional Dome Lid
|
|
Drain Valve
|
None
|
Mounted(Φ9.5~11mm)
|
|
Dimension (w×d×h)
|
Effective Space
|
300×155×h110mm
|
302×240×h110mm
|
500×295×h110mm
|
|
Internal
|
300×155×h150mm
|
302×240×h150mm
|
500×295×h150mm
|
|
External
|
325×180×h260mm
|
325×265×h260mm
|
535×330×h260mm
|
|
Packing Size (mm) and Gross Weight (kg)
|
350×210×h310mm,
8 kg
|
350×300×h310mm,
10 kg
|
570×360×h310mm,
14 kg
|
|
Power Supply�
|
1 Phase, AC 120 V, 60 Hz or AC 230 V, 50 / 60 Hz
|
