Capacity & Models
|
6 Lit.
“WCB - 6”
|
11 Lit.
“WCB - 11”
|
22 Lit.
“WCB - 22”
|
- Range & Accuracy
|
Ambient＋5℃~ 100℃, ±0.1℃
|
|
Temp. Resolution
|
0.1℃-Display, 0.1℃-Control
|
- Uniformity & Probe
|
±0.2℃, PT100
|
|
Heating Power
|
800 W
|
1 kW
|
2 kW
|
|
Pump
|
5 Lit. / min (Internal / External)
|
|
Circulation Nozzle
|
i.d. 7×o.d. 11 mm (i.d. 9 / o.d. 12mm silicon tube connected for inner circulation)
|
|
Timer & Alarm
|
99hr 59min (Delay & Continuous run), Error status & Timer-end
|
|
Display
|
Digital LCD with Back- Light Function
|
|
Controller
|
Digital Fuzzy Controller with Jog - Shuttle Switch (Turn＋Push)
|
|
Safety Circuit
|
Over-Temp./-Current protection, Sensor Error & Low Level Detection
|
|
Material
|
Stainless steel (＃304)-Internal, Powder Coated steel-External
|
|
Lid
|
included Stainless steel Flat Lid, Optional Dome Lid
|
|
Drain Valve
|
None
|
Mounted(Φ9.5~11mm)
|
|
Dimension (w×d×h)
|
Effective Space
|
120×155×h150 mm
|
170×240×h150 mm
|
372×295×h150 mm
|
|
Internal
|
300×155×h150 mm
|
302×240×h150 mm
|
500×295×h150 mm
|
|
External
|
330×185×h385 mm
|
335×275×h385 mm
|
540×335×h410 mm
|
|
Packing Size (mm) and Gross Weight (kg)
|
350×210×h410mm,
11 kg
|
360×300×h420mm,
13 kg
|
580×380×h470mm,
18 kg
|
|
Power Supply�
|
1 Phase, AC 120 V, 60 Hz or AC 230 V, 50 / 60 Hz
|
