- Model
|
(1) “HS-30T”
|
(2) “HS-100T”
|
|
Stirring Capacity
|
Max. 10 Lit. (H2O)
|
Max. 20 Lit. (H2O)
|
|
Maximum Viscosity / Torque
|
10,000 mPas / 85 Ncm
|
50,000 mPas / 145 Ncm
|
|
Speed Range & Motor
|
200 ~ 3,000 rpm, Direct Driven DC Motor
|
|
Motor Rating (Input / Output)
|
83 / 75 W, 1/10 HP
|
130 / 120 W, 1/6 HP
|
|
Timer & Alarm
|
99hr 59min (with Continuous run.), Timer-end Alarm
|
|
Controller / Display
|
Digital Feedback Controller / Digital LCD with Back-Light Function
|
|
Chuck Grip Capa. Φmm
|
dia Φ3~10mm Shafts
|
|
“Push-Through” Shafts
|
dia Φ8mm or Less
|
|
Permissible Temp. & Humidity
|
0 ~ 40℃, 80%
|
|
Safety Device / Material
|
Overload & Heat Protector for motor / ABS and Aluminum
|
|
Dimension & Weight*
|
90×100×h180mm, 3 kg
|
90×100×h180mm, 3.8 kg
|
|
Packing Size & Gross Weight
|
580×340×h230mm, 5 kg
|
580×340×h230mm, 8 kg
|
|
Power Consumption
|
75 W
|
120 W
|
|
Electrical Reqts.
|
1 Phase, AC 120 V, 60 Hz or AC 230 V, 50 / 60 Hz
|
|
Stand Package-set
|
|
Cat. No.
|
230V
|
DH.WOS01036
|
DH.WOS01046
|
|
120V
|
DH.WOS02036
|
DH.WOS02046
|
|
Price, Each. ￦
|
589,000
|
633,000
|
|
Unit & Remote Controller
|
|
Cat. No.
|
230V
|
DH.WOS01035
|
DH.WOS01045
|
|
120V
|
DH.WOS02035
|
DH.WOS02045
|
|
Price, Each. ￦
|
486,000
|
471,000
|
