Models
|
ThermoStable
IR-150
|
ThermoStable
IR-250
|
ThermoStable
IR-420
|
ThermoStable
IR-700
|
|
Capacity
|
150 Lit.
|
250 Lit.
|
420 Lit.
|
700 Lit.
|
|
Air Flow-type
|
Forced Convection-type
|
|
Temp. Range & Accuracy
|
0 ℃ ~ 60 ℃, ± 0.2℃ at 37℃
|
|
Temp. Uniformity & Sensor
|
±0.5℃ at 37℃, ±1.4℃ at 50℃, PT100 Sensor
|
|
Heat-up Time
|
20 min. to 37 ℃
20 min. to 50 ℃
|
35 min. to 37 ℃
35 min. to 50 ℃
|
|
Recovery Time
(Door open 30sec)
|
10 min. to 37 ℃
12 min. to 50 ℃
|
12 min. to 37 ℃
15 min. to 50 ℃
|
|
Heating Power/Consumption
|
700 W
|
1 kW
|
1.2 kW
|
2 kW
|
|
Compressor
|
1/4 HP
|
1/3HP
|
1/2 HP
|
1/2HP
|
|
Compressor Control
|
Intelligent Control of Refrigerator for preventing Overload of Compressor
|
|
Refrigerant
|
CFC-Free(R-404A) Refrigeration System
|
|
Timer & Alarm
|
99hr 59min (with delay / Continuous run.), Error status & Timer-end
|
|
Display
|
Digital LCD with Back Light
|
|
Controller
|
Digital Fuzzy Controller with Jog-Shuttle Switch (Turn & Push)
|
|
Inner Door
|
with 1ea of Inner Tempered Glass Door
|
|
Shelves
|
Included 3ea of Teflon-coated steel Shelves
|
|
Permitted Total Load
|
Total Load : 48 kg (16kg×3 Shelves)
|
|
Safety Circuit
|
Over Temp. and Over Current Protector, Sensor Error Detector
|
|
Material
|
Internal : Stainless steel (＃304), External : Powder Coated steel
|
|
Dimension (w×d ×h)
|
Interior (mm)
|
505×505×610
|
505×505×1,000
|
705×605×1,000
|
800×700×1,250
|
|
Exterior (mm)
|
640×832×1,313
|
640×832×1,703
|
840×932×1,753
|
935×1,027×2,000
|
|
Net Weight
|
118 kg
|
157 kg
|
202 kg
|
234 kg
|
|
Packing Size (w×d×h) (mm)
& Gross Weight
|
900×1,000×1,650
191 kg
|
900×1,000×2,040
217 kg
|
1,100×1,100×2,140
277 kg
|
1,220×1,220×2,260
313 kg
|
|
Power Consumption
|
1.6 kW
|
1.8 kW
|
2.3 kW
|
2.4 kW
|
|
Power Supply & Cord/Plug*
|
1 Phase, AC 120 V, 60 Hz or AC 230 V, 50 / 60 Hz
|
