- Model
|
(1) “HT-50AX”
|
(2) “HT-120AX”
|
|
Stirring Capacity
|
Max. 50 Lit. (H2O)
|
Max. 80 Lit. (H2O)
|
|
Maximum Viscosity / Torque
|
100,000 mPas / 300 Ncm
|
150,000 mPas / 500 Ncm
|
|
Speed Range & Motor
|
0 ~ 1,000 rpm, Worm-Geared DC Motor (3.5:1 Ratio)
|
|
Motor Rating (Input / Output)
|
83 / 75 W, 1 / 10 HP
|
130 / 120 W, 1 / 6 HP
|
|
Controller
|
Analog Phase Controller
|
|
Chuck Grip Capa. Φmm
|
dia Φ6~12mm Shafts
|
|
“Push-Through” Shafts
|
dia Φ10mm or Less
|
|
Permissible Temp. & Humidity
|
0 ~ 40℃, 80%
|
|
Safety Device / Material
|
Over Heat Protector for motor / ABS and Aluminum
|
|
Dimension & Weight
|
90×180×h130mm, 3.5 kg
|
90×210×h130mm, 4 kg
|
|
Packing Size & Gross Weight
|
320×300×h180mm, 5 kg
|
320×300×h180mm, 8 kg
|
|
Power Consumption
|
85 W
|
130 W
|
|
Electrical Reqts.
|
1 Phase, AC 120 V, 60 Hz or AC 230 V, 50 / 60 Hz
|
|
Stand Package-set
|
|
Cat. No.
|
230V
|
DH.WOS01252
|
DH.WOS01272
|
|
120V
|
DH.WOS02252
|
DH.WOS02272
|
|
Price, Each. ￦
|
454,000
|
516,000
|
|
Unit-only
|
|
Cat. No.
|
230V
|
DH.WOS01251
|
DH.WOS01271
|
|
120V
|
DH.WOS02251
|
DH.WOS02271
|
|
Price, Each. ￦
|
356,000
|
417,000
|
