- Model
|
“WEV-1001V”
|
“WEV-1001L”
|
|
Condenser Type
|
Vertical-type
|
Diagonal-type
|
|
Flask Capacity
|
Evaporating
|
Included 2×Evaporating Flasks : 1×0.5Lit. & 1×1Lit.,
Available 100~2,000㎖Evaporating Flask(Optional)
|
|
Receiving
|
Included 1ea 1 Lit. Flask
|
|
Rotary Speed
|
10 ~ 180 rpm
|
|
Evaporating Capability
|
20 ml/min
|
|
Cooling Surface
|
1,300 cm2
|
|
Achievable Vacuum
|
399.9Pa(below 3mmHg)
|
|
Bath Capacity
|
7.4 Lit. / Φ260×140 mm
|
|
Temp. Range
|
Ambient Temperature +5℃ ~ 99℃
|
|
Functional of Lifting Table
|
Weight Balancing Gliding Elevating & Manual Lifting
|
|
Elevating Stroke
|
100 ~ 250 mm
|
|
Vacuum Sealing
|
Double Sealing Rings made of Teflon+Vinton Materials
|
|
Power Consumption
|
Motor : 25 W, Heater : 1.5KW
|
|
Controller & Display
|
PID Controller, Digital display
|
|
Dimension & Net Weight
|
560×320×h660mm / 9.5 kg
|
750×320×h540mm / 9.5 kg
|
|
Power Supply & Cord Plug
|
220V, 60Hz
|
