- Model
|
ThermoStableTM IF-50
|
ThermoStableTM IF-105
|
ThermoStableTM IF-155
|
|
Capacity
|
50 Lit.
|
105 Lit.
|
155 Lit.
|
|
Dimension
(w×d×h)
|
Interior (mm)
|
370×350×419
|
485×410×533
|
550×475×600
|
|
Exterior (mm)
|
518×637×700
|
635×695×841
|
700×760×906
|
|
Heater Power
|
200W
|
300W
|
400W
|
|
|
Range
|
Room Temp. +5℃ to 70℃
|
|
Fluctuation
|
± 0.2℃ at 37℃, ± 0.3℃ at 50℃
|
|
Variation
|
± 0.5℃ at 37℃,
± 0.9℃ at 50℃
|
± 0.4℃ at 37℃,
± 0.7℃ at 50℃
|
|
Sensor
|
PT 100
|
|
Control Resolution
|
±0.1℃
|
|
Heat-up Time
|
17 min. to 37℃, 28 min. to 50℃
|
17 min. to 37℃, 30 min. to 50℃
|
|
Recovery Time (Door open 30sec)
|
3 min. to 37℃, 4 min. to 50℃
|
|
Controller
|
Digital PID Control by Advanced Microprocessor Jog-Dial with Push Button
|
|
RS232 Port
|
Available to connect with PC
|
|
Display
|
Digital LCD with Back Light
|
|
Timer
|
99hr 59 min (delay/continuous function)
|
|
Material
|
Internal
|
Stainless-steel (#304)
|
|
External
|
Powder Coated steel
|
|
Inner Door
|
Inner Tempered Glass Door
|
|
Shelves
|
2ea of PE-coated steel Wire Shelves included, Load per Shelf : 16 kg
|
|
Ventilation
|
1ea of Ventilation hole with Stainless steel Cap, Hole Diameter 40mm
|
|
Circulation
|
Forced-air Type
|
|
Safety device
|
Over Temp. and Over Current Protector, Sensor Error Detector
|
|
Others
|
UL/CUL Certified, CE Certified, GD-mark Storage Function(Temp. and Time) Locking Mode(Jog-Dial Input Disabled) Alarm (Error Status and Timer-end)
|
|
Net Weight (kg)
|
46
|
66
|
81
|
|
Packing Size (w×d×h) (mm)
|
628×752×775
|
710×731×1,018
|
731×810×1,018
|
|
Shipping Weight (kg)
|
58
|
74
|
92
|
|
Power Consumption
|
216.3 W
|
302.9 W
|
438.1 W
|
|
Energy Consumption, at 37℃
, at 50℃
|
28 Wh
|
43 Wh
|
58 Wh
|
|
84 Wh
|
129 Wh
|
145 Wh
|
|
Electrical Reqts.
|
120V, 60Hz or 230V, 50/60Hz
|
