Number of Stirring Points & Models
|
4 (2×2) Stirring Points “MS-MP4”
|
8 (4×2) Stirring Points “MS-MP8”
|
|
Plate Size (mm)
|
210×300
|
210×500
|
|
Stirring Capacity (H2O)
|
Max. 0.5 Lit. per Point
|
|
Distance between Stirring Points
|
100 mm
|
|
Speed Range
|
80 ~ 1,200 rpm
|
|
Motor Rating
|
16/9 W
|
|
Speed Control Resolution
|
5 rpm
|
|
Timer & Alarm
|
99hr 59min (with Continuous run.), Error status & Timer-end
|
|
Display
|
Digital LCD with Back-Light Function
|
|
Controller
|
Digital Feedback Controller with Jog Shuttle Switch(Turn+Push)
|
|
Stirring Bar
|
3cm bar-included, Usable : up to 3cm bar
|
|
Permissible Ambient Temperature
|
Ambient +5 ~ 50℃
|
|
Permissible Relative Moisture
|
85%
|
|
Material
|
Plate
|
Stainless steel (＃304)
|
|
Body
|
Power Coated Steel
|
|
Dimension (w×d×h) (mm)
|
210×300×65
|
210×500×65
|
|
Weight
|
2.5 kg
|
3.5 kg
|
|
Others
|
CE Certified, PL(Product Liability) Insurance Storage Function (RPM, Timer)
Locking Mode (Jog-Shuttle Input Disabled) Alarm (Error Status and Timer-end)
|
|
Packing Size (w×d×h) (mm) & Gross Weight
|
330×300×180
|
540×330×180
|
|
6 kg
|
|
Power Consumption
|
20 W
|
|
Power Supply & Cord/Plug*
|
Free Voltage (1 Phase, AC 80 ~ 240 V, 50 / 60 Hz)
|
