Number of Plates, Models
|
3×1 Plates-type “SMHS-3”
|
3×2 Plates-type “SMHS-6”
|
|
Material
|
Plate : Ceramic Coated Aluminum, Body : Powder Coated Steel
|
|
Plate Size(mm)
|
140×140
|
|
Stirring Capa. & Motor Rating
|
Max. 20 Lit.(H2O), 9/4W×3
|
Max. 20 Lit.(H2O), 9/4W×6
|
|
Speed & Control Resolution
|
80 ~ 1,500 rpm, 5 rpm
|
|
Temp. Range & Accuracy
|
Max. 350 ℃, ±0.3℃ at Set Temp.
|
|
Temp. Resolution
|
0.1 ℃-Display, 0.5 ℃-Control
|
|
Temp. Uniformity
|
Specially Designed Heating Module : Temp. Difference 10% less
|
|
Heating Power/Consumption
|
400 W ×3 Plates
|
400 W ×6 Plates
|
|
Timer & Alarm
|
99hr 59min (with Continuous run.), Error status & Timer-end
|
|
Display
|
Digital LCD Display with Back- Light Function
|
|
Controller
|
Digital Feedback Controller with Jog Shuttle Switch (Turn+Push)
|
|
Stirring Bar
|
3cm bar-included, Usable : up to 5cm bar
|
|
Permissible Temp. & RH %
|
Ambient +5 ~ 50℃, 85% RH
|
|
Dimension & Weight
|
510×240×h100mm, 10kg
|
510×410×h180mm, 18kg
|
|
Packing Size & Gross Weight
|
540×330×h170mm, 10kg
|
570×540×h230mm, 18kg
|
|
Power Supply *
|
1 Phase, AC 120 V, 60 Hz or AC 230 V, 50 / 60 Hz
|
