Technical data for steam distillers
|
|
S 1
|
S 2
|
S 3
|
S 4
|
S 5
|
|
Voltage
|
230 VAC/115 VAC
|
|
Frequency
|
50/60 Hz
|
|
Power consumption
|
1700 W
|
|
Current consumption
|
9 A/18 A
|
|
Cooling water consumption
|
approx. 5 l/min
|
|
Distillation time
|
approx. 2 - 4 min per sample
|
|
Storage container
|
Any size required. Recommendation: behrotest® KAS canister sets
|
|
Interface
|
USB
|
|
Display
|
LCD
|
|
Programs
|
1
|
1
|
10
|
100
|
100
|
|
Dimensions (W x H x D in cm)
|
approx. 41 x 67.5 x 41
|
|
Weight
|
approx. 32 kg
|
approx. 34 kg
|
approx. 35 kg
|
approx. 35 kg
|
approx. 36 kg
|
|
Titrator connection
|
no
|
no
|
no
|
no
|
yes
|
Features of the various units
|
|
S 1
|
S 2
|
S 3
|
S 4
|
S 5
|
|
Automatic addition of H2O
|
–
|
+
|
+
|
+
|
+
|
|
Automatic addition of NaOH
|
+
|
+
|
+
|
+
|
+
|
|
Automatic addition of H3BO3
|
–
|
–
|
–
|
+
|
+
|
|
Manual addition of H2O
|
–
|
+
|
+
|
+
|
+
|
|
Manual addition of NaOH
|
+
|
+
|
+
|
+
|
+
|
|
Manual addition of H3BO3
|
–
|
–
|
–
|
+
|
+
|
|
Automatic extraction of the sample residues
|
–
|
–
|
+
|
+
|
+
|
|
Number of programs
|
1
|
1
|
10
|
99
|
99
|
|
Titrator connection option
|
–
|
–
|
–
|
–
|
+
|
|
|
|
Programmable reaction time
|
+
|
|
Programmable distillation time
|
+
|
|
Automatic steam generation
|
+
|
|
Adjustable steam output (40% – 100%)
|
+
|
|
Separate purging program
|
+
|
|
Display language selectable by user
|
+
|
|
Optical error indications
|
+
|
|
Acoustic error indications
|
+
|
|
Door safety contact switch
|
+
|
|
USB interface
|
+
|
|
Standby mode between distillations
|
+
|
|
Level monitoring for the canister set
|
+
|
|
Different glass digestion tubes can be used
|
+
|
