(1) Standard-model
|
MaXterile 47
|
MaXterile 60
|
MaXterile 80
|
MaXterile 100
|
|
Standard-type
|
|
(2) Recorder-model
|
MaXterile 47R
|
MaXterile 60R
|
MaXterile 80R
|
MaXterile 100R
|
|
Recorder-type : Built in Recording Printer, Sterilization Cycle Data (Date, Temperature, Pressure, Time, Error Status, etc.)
|
|
Capacity
|
47 Lit.
|
60 Lit.
|
80 Lit.
|
100 Lit.
|
|
Temp. Range & Accuracy
|
Ambient +5℃ to 132℃, ±0.5℃ at 121℃
|
|
Pressure & Gauge
|
- 2 kgf/cm2 at 121℃/ 2.0 kgf/cm2 at132℃, 0 ~ 3 kgf/cm2
|
|
Sterilization mode
|
Solid- or Liquid-mode
|
|
Heating Power/Consumption
|
2 kW
|
3 kW
|
2 kW×2
|
2 kW×2
|
|
Timer & Alarm
|
60 min, Error status & Timer-end
|
|
Display
|
Digital LCD with Back-Light Function
|
|
Controller
|
Digital Fuzzy-Control System (Fully Automatic)
|
|
Door & Closing System
|
Lever-type Sliding Door / Safety Electronic Door Closing System
|
|
Safety Circuit
|
Over-Temp./-Pressure/-Current protection, Sensor Error Detection
|
|
Printer
|
Thermal type printer, Record Paper Roll: w58 ×Φ40 mm
|
|
Material
|
Stainless steel (＃304)-Pressure Vessel, Powder Coated steel-External
|
|
Basket
|
2ea of Stainless steel Wire Baskets are Included
|
|
Basket Dimension (mm)
|
Φ270×h240
|
Φ320×h240
|
Φ370×h240
|
Φ420×h240
|
|
Dimension (w×d×h)
|
Inner (mm)
|
Φ300×h670
|
Φ350×h650
|
Φ400×h650
|
Φ450×h630
|
|
Outer (mm)
|
680×470×880
|
680×470×900
|
780×580×900
|
780×580×900
|
|
Packing Size (mm)
|
840×610×h1,252 mm
|
950×730×h1,352 mm
|
|
Gross Weight (kg)
|
117 kg
|
120 kg
|
170 kg
|
170 kg
|
|
Power Supply�
|
1Phase - AC 120V, 60Hz or
- AC 230V, 50/60Hz
|
1 Phase - AC 120V, 60Hz or - AC 230V, 50/60Hz
3 Phase - AC 380V, 50/60Hz
|
