Technical details
|
|
Spectral range
|
1,000 - 1,900 nm
|
|
Spectral resolution
|
10 nm
|
|
Stray light
|
< 0.2 %
|
|
Measuring time
|
< 5 s per scan (average 500 scans)
|
|
Detector
|
InGaAs single detector, uncooled
|
|
Software
|
- QuickStep software for data acquisition and visualisation; optional: platform-indepen- dent drivers and software development kit for integration into your own application (operating system: Windows 7 SP1, Windows 8.1, Windows 10, Linux (x86/x64/ARM))
- Sensologic for data acquisition and generation of chemometric modells (operating system: Windows 7, Windows 8.1, Windows 10 (32 Bit System))
|
|
Storage temperature
|
-20 to 60 °C (non-condensing)
|
|
Wavelength accuracy
|
± 0.5 nm
|
|
Wavelength reproducibility
|
± 0.2 nm
|
|
Photometric reproducibility
|
± 0.1 %
|
|
Photometric linearity deviation (max/RMS)
|
1 % / < 1 %
|
|
Light source
|
Tungsten halogen lamp
|
|
Probe/optical input
|
Diffuse reflection, 23 mm diam.
|
|
Thermal stabilisation
|
Yes, @ 55°C
|
|
Dimensions
|
225 x 235 x 385 mm3
|
|
Weight
|
9 to 9.5 kg depending on configuration
|
|
Interfaces
|
USB type B (additional electronical interface, e.g. for motor control or sensor input)
|
|
Power supply
|
12 V/8.5 A DC
|
|
Operating temperature
|
15 to 35 °C
|
|
SNR
|
2,000:1 (average 2,000 scans); 1,000:1 (average 500 scans)
|
|
Power consumption
|
36 W / 5 W (sleep mode)
|
