Vacuum type
|
Non-Vacuum type
|
|
Capacity: 17 &22 liters
|
|
|
|
Load weight: 5 kg approximate
|
|
|
|
Operating Pressure : 15 PSI / 121°C
30 PSI / l 34°C
|
|
|
|
Chamber Diameter : 240 mm
|
|
|
|
Chamber length: 360mm
|
|
|
|
Maximum instrument length: 300mm
|
|
|
|
Overall productl: L530 x W390 x H420 mm
|
|
|
| Water reservoir capacity : 4.5 liters (4,500 c.c .) |
|
|
|
Program l (Unwrapped)
l 34°C/ 4min, 4 minutes sterilizing at l 34°C, 30 minutes drying
|
|
|
|
Program 2 (Pouches)
l 34°C/ l 8min, 18 minutes sterilizing at l 34°C, 30 minutes drying
|
|
|
|
Program 3 (Liquids)
l 21°C/ 30min, 30 minutes sterilizing at l34°C, no drying process
|
|
|
|
Program 4 (Packs)
121°C/ 30min, 30 minutes ste rilizing at 121°C, 30 minutes drying
|
|
|
|
Voltage options
|
230V
|
230V or 115V
|
|
Net Weight
|
41 kgs
|
39 kgs
|
|
Gross Weight
|
49 kgs
|
46 kgs
|
|
Standard Package
|
Waterfilter
Water tube ( 2.5M tor draining water) Spanner
Watertray Tray Rack
Tray handle
|
