Models
|
ThermoStable
IG-32
|
ThermoStable
IG-50
|
ThermoStable
IG-105
|
ThermoStable
IG-155
|
|
Capacity
|
32 Lit.
|
50 Lit.
|
105 Lit.
|
155 Lit.
|
|
Dimension (w×d ×h)
|
Interior (mm)
|
312×290×360
|
370×350×420
|
485×410×535
|
550×475×600
|
|
Exterior (mm)
|
458×477×624
|
518×537×701
|
635×595×841
|
700×660×906
|
|
Heater Power
|
150W
|
200W
|
300W
|
400W
|
|
|
Range
|
Ambient Temperature +5℃ to 70℃
|
|
Fluctuation
|
± 0.2℃ at 37℃, ± 0.3℃ at 50℃
|
|
Variation
|
± 0.6℃ at 37℃, ± 1.0℃ at 50℃
|
|
Sensor
|
PT 100
|
|
Control Resolution
|
±0.1℃
|
|
Heat-up Time
|
25 min. to 37 ℃ ,
40 min. to 50 ℃
|
30 min. to 37 ℃ ,
40 min. to 50 ℃
|
|
Recovery Time (Door open 30sec)
|
8 min. to 37 ℃
12 min. to 50 ℃
|
10 min. to 37 ℃
15 min. to 50 ℃
|
|
Controller
|
Digital Fuzzy Control by Advanced Microprocessor Jog-Dial with Push Button
|
|
RS232 Port
|
Available to connect with PC
|
|
Display
|
Digital LCD with Back Light
|
|
Timer
|
99hr 59 min (delay/continuous function)
|
|
Material
|
Internal
|
Stainless steel (#304)
|
|
External
|
Powder Coated steel
|
|
Inner Door
|
Inner Tempered Glass Door
|
|
Shelves
|
2ea of Teflon-coated steel Wire Shelves included, Load per Shelf : 16 kg
|
|
Ventilation
|
1ea of Ventilation hole with Stainless steel Cap, Hole Diameter 40mm
|
|
Circulation
|
Gravity Convection Type
|
|
Safety device
|
Over Temp. and Over Current Protector, Sensor Error Detector
|
|
Others
|
UL/CUL Certified, CE Certified, GD-mark Storage Function (Temp. and Time) Locking Mode (Jog-Dial Input Disabled) Alarm (Error Status and Timer-end)
|
|
Net Weight (kg)
|
32
|
40
|
59
|
71
|
|
Packing Size (w×d×h) (mm)
|
568×592×698
|
628×652×775
|
731×710×1,018
|
796×775×1,083
|
|
Shipping Weight (kg)
|
39
|
53
|
67
|
78
|
|
Power Consumption
|
159 W
|
169.9 W
|
292.9 W
|
420.5 W
|
|
Energy Consumption, at 37°C
, at 50°C
|
34 Wh
|
41 Wh
|
63 Wh
|
99 Wh
|
|
81 Wh
|
103 Wh
|
152 Wh
|
212 Wh
|
|
Power Supply
|
1Phase 120V, 60Hz or 230V, 50/60Hz
|
